Integrated vertical three-jaw chuck and rotating spindle.

Multiple models are available for selection. There is a one-year quality warranty and customization is supported.

Small High-Speed ​​Spindle

Precision: 0.03mm
Clamping Range: 8mm - 40mm

Rotary Spindle Integration (Vertical)

Precision: 0.03mm
Clamping Range: 27mm - 50mm

High-Precision Spindle Integration (Vertical)

Precision: 0.005mm
Clamping Range: 30mm - 65mm

DRS High-precision Rotary Spindle Integration (Vertical Installation)

It has a large through hole, with the maximum diameter of the through hole being 46mm. It is driven to rotate by being connected to a motor through synchronous pulley or gear transmission, which is convenient and simple.

Front-mounted Hollow Rotary Spindle Chuck Holder - External-mounted Type

The opening stroke is 2.5mm, and a 50mm opening stroke can be customized. It has a large through hole and can hold a maximum diameter of 500mm.

Pneumatic Spindle Integration

Precision: 0.03mm
Clamping Range: 0.2mm - 25mm

DR-L High-precision Rotary Spindle Integration (Horizontal Installation)

It features high precision, with the spindle rotation accuracy within 0.005mm. It has a high rotational speed, and the maximum rotational speed is 3,500 revolutions per minute. It has a large through hole, and the maximum diameter of the through hole

Rotary Spindle Integration (Horizontal)

Precision: 0.03mm
Clamping Range: 8mm - 90mm

Passive high-precision chuck (pull-back type)

Precision: 0.01mm
Clamping Range: 15mm - 19mm

Fixed hydraulic chuck (push-forward type)

Precision: 0.03mm
Clamping Range: 0.2mm - 16mm

Large stroke hydraulic fixed chuck

Precision: 0.03mm
Clamping Range: 0.2mm - 25mm
