Small installation outer diameter, large through-hole
High precision clamping repeatability within 0.01 mm
Chuck Internal Expansion and External Clamping
No additional cylinders (hydraulic cylinders) required
Operating air pressure: 3-8 kg/cm2; dustproof waterproof
Suitable for various precision specialized machines
grinding machines, 4-axis and 5-axis machines
inspection equipment, similar applications
